- Aeration Kit for Ponds up to 4 acres
- Maximum operation depth of 50 feet
- 3/4 hp Stratus SRC75 Gen 2 compressor with two year warranty
- Four valve manifold with pressure relief
- Valved outlet with heat reducing hose and 3/8″ connections
- Four QS2 Quick Sink self weighted dual head air diffusers
- 600′ 3/8″ Quick Sink weighted tubing
- Approximately 1.6 cfm of air flow per diffuser
- Typical operation cost of $1.10 per 24 hours at .09¢ per kWh, actual cost may vary
- PA86W requires weather protection for the compressor
- 2 Year Warranty on Compressor
- 5 Year Warranty on Tubing and Diffusers
- Tubing 600 ft 3/8" Quick Sink
- Horsepower 3/4 HP
- Voltage 115v or 230v
- Amps 4.5/2.3 amps (at 10' operating depth)
- Maximum Air Flow 6.5 cfm
- Maximum Depth 50'
- In Aeration Acres Up to 4 acres
Complete aeration system for ponds up to four acres depending on shape and depth of pond. 3/4 hp Rocking Piston SRC75 compressor, 6.5 cfm, 4.5 amps, aerates up to 50′ deep. The PA86W kit also includes four QS2 Quick Sink air diffusers, four valved outlet assembly with pressure relief valve, 600′ of 3/8″ Quick Sink tubing, fittings and clamps.
